Hardware:
|
Processor: |
Allwinner 533 |
| DDR： |
DDR3 1GB |
| SENSOR： |
2093 |
| Camera specifications: |
2093/2K/2G2P1R/F2.0Aperture/D:134.6°/H：111.4°/V：57.8°/17MM outer ring diameter/x22（height） |
| Expansion cards： |
Support TF card (microSD card), the maximum support 128GB expansion |
| Collision sensors: |
Three-axis acceleration sensor (optional) |
| Physical Keys: |
POWER |
| Speakers: |
8ohm,1W |
| WiFi |
WiFi mobile interconnection 2.4G&5G |
| Battery type: |
Built-in lithium battery |
| Microphone: |
Cylindrical MIC-2X4MM, 42+-3dB |
| Touch: |
2.5D In-cell 9.66 inches
|
| |
|
| |
|
|
LCD screen
|
Screen size: |
9.66-inch IPS screen |
| Screen resolution: |
1280*320 |
| |
|
| |
|
|
Functional Features
|
GPS: |
support |
| Language： |
Traditional Chinese, Simplified Chinese , English,Japanese...and many other
languages |
| Start time |
5S |
| Previous videore solution: |
2K(2560x1440)、1080P(1920x1080) |
| Post video resolution |
1920*1080P 30 fp/s |
| Photo resolution: |
(2560x1440)
2MHD(1920x1080) |
| Type of coding: |
H.264 |
| Video coding format: |
MP4 |
| Photo Format: |
JPEG |
| Parking monitoring: |
support |
| Loop video: |
turn off, 1 minute, 2 minutes, 5 minutes |
| Motion detection: |
support |
| Voice control: |
Support (Show front, show back, close recording, open recording, I want to take a photo, video lock)
|
| Document locking: |
support |
| Astern rearview: |
Support (Support reversing ruler height adjustment) |
| Screen brightness adjustment: |
support |
| Time-lapse recording: |
support |
| Screen saver: |
turn off,10 seconds, 30 seconds, 1 minute |
| |
|
| |
|
|
Interface
|
Rear view interface: |
2.5m 3 AHD camera ports |
| USB interface: |
mini USB（Power/Download) |
| |
|
|
Power source
|
Operating voltage: |
DC5V 2A |
| Working current: |
< 610mA(typical value) (DC5V) |
| Static current: |
2ma |
| Working temperature: |
（-10℃-70℃） |
| Storage temperature: |
（-20℃-75℃） |
| |
|
| |
|
|
Accessories
|
Mount: |
Strap, special support (optional) |
| MCU voltage reduction line: |
Micro-USB-5P:2.5A |
| Instruction: |
neutral |
